Image Sharpness with High Contrast Ratio
The high contrast ratio brings out the subtle differences in similar shades of gray and sharper rendering of details when displaying monochrome images such as the digital mammography, MRI, and ultrasound images.
10-Bit Simultaneous Grayscale Display
10-bit (1,024 tones) simultaneous grayscale display extends grayscale fidelity to the boundaries of human visual perception abilities and helps radiologists discern the finest nuances within an image.
10-bit graphics board and 10-bit viewer software needed for 10-bit display.
Wide Viewing Angles for Multiple People Use
Wide Viewing angles with minimal color shift when viewed from the side.
Mode Selection for Optimum Viewing
Selectable with the front panel buttons, the CAL Switch function allows for various imaging modes of different modalities such as digital mammography, ultrasound, and MRI images. Furthermore, with ScreenManager Pro for Medical installed, auto mode settings can be made with the Auto CAL Switch function.
Digital Mammography Monitor Quality Control Standards Compliance
EIZO's easy-to-use RadiCS UX1 quality control tool (sold separately) performs precise calibration conforming to DICOM Part 14 and enables quality control complying with ACR Practice Guideline and other QC standard for digital mammography monitors.
5 Year Warranty
EIZO and its authorized distributors offer a five-year limited warranty.
Diagnostic Precision with DICOM Part 14 Factory Adjustment
To ensure the most accurate and consistent shadings possible, EIZO carefully measures and sets every grayscale tones on the production line to produce a monitor compliant with DICOM Part 14.
Easy Calibration with Integrated Front Sensor
An Integrated Front Sensor housed within the front bezel performs calibration compliant to DICOM Part 14. The sensor does not interfere with the viewing area and is protected from inadvertent damage or removal.
High-Resolution
With a resolution of 5 megapixels or higher, the monitors meet the high level standards required for displaying digital mammography.
Quick Brightness Stabilization for Instant Viewing
At startup or upon wakeup, the EIZO patented drift correction function quickly stabilizes the brightness level. In addition, a sensor measures the backlight brightness and compensates for brightness fluctuations caused by the ambient temperature and the passage of time.
Presence Sensor for Power Savings
The presence sensor feature unites convenience with savings by ensuring that the monitor conserves power when it is not in use. The presence sensor prompts the monitor to switch to power save mode when it detects the user is away from the monitor, and then resume normal operation when the user returns.
Brightness Stability Within Usage Time Guaranteed
EIZO's confidence in its product quality extends to brightness stability which is also covered during the usage time specified in the warranty.
Customer Assurance with Medical Standards
Meets the strictest medical, safety, and EMC emission standards.
| Model Variations |
GX530-CL: Clear Base
GX530-CL-P: Pairing GX530-BL: Blue Base GX530-BL-P: Pairing |
|---|---|
| Cabinet Color | Black |
| Panel | |
| Type | TFT Monochrome LCD Panel (IPS) |
| Backlight | CCFL |
| Size | 54 cm / 21.3" (540 mm diagonal) |
| Native Resolution | 2048 x 2560 |
| Display Size (H x V) | 337.9 x 422.4 mm |
| Pixel Pitch | 0.165 x 0.165 mm |
| Grayscale Tones |
10-bit (DisplayPort): 1,024 from a palette of 16,369 tones
8-bit: 256 from a palette of 16,369 tones |
| Viewing Angles (H / V, typical) | 170°, 170° |
| Brightness (typical) | 1,200 cd/m2 |
| Recommended Brightness for Calibration | 500 cd/m2 |
| Contrast Ratio (typical) | 1200:1 |
| Response Time (typical) | 25 ms (On/Off) |
| Video Signals | |
| Input Terminals | DVI-D (dual link) x 1, DisplayPort x 1 |
| Digital Scanning Frequency (H / V) |
31 - 135 kHz / 24 - 61 Hz
Frame synchronous mode: 24.5 - 25.5 Hz, 49 - 51 Hz |
| USB | |
| Function | 1 upstream, 2 downstream |
| Standard | Rev. 2.0 |
| Power | |
| Power Requirements | AC 100 - 120 V, 200 - 240 V: 50 / 60 Hz |
| Maximum Power Consumption | 130 W |
| Typical Power Consumption | 64 W |
| Power Save Mode | Less than 2.5 W |
| Power Management | DVI DMPM, DisplayPort 1.1a |
| Sensor | Backlight Sensor, Integrated Front Sensor, Presence Sensor, Ambient Light Sensor |
| Features & Functions | |
| Brightness Stabilization | Yes |
| Preset Modes | CAL-Switch |
| Digital Uniformity Equalizer | Yes |
| OSD Languages |
English, German, French, Italian, Japanese, Simplified
Chinese, Spanish, Swedish, Traditional Chinese |
| Physical Specifications | |
| Net Weight | 10.5 kg |
| Net Weight (Without Stand) | 7.8 kg |
| Hole Spacing (VESA Standard) | 100 x 100 mm |
| Certifications & Standards (Please contact the EIZO group company or distributor in your country for the latest information.) | CE (Medical Device Directive), EN60601-1, UL60601-1, CSA C22.2 No. 601-1, IEC60601-1, VCCI-B, FCC-B, Canadian ICES-003-B, C-tick, RoHS, China RoHS, WEEE, CCC, GOST-R |
| FDA 510(k) Clearance | Yes (for Mammography and General Radiography) |
| Supplied Accessories | AC power cord, dual link signal cable (DVI-D - DVI-D), signal cable (DisplayPort - DisplayPort), USB cable, Utility Disk (RadiCS LE, ScreenManager Pro for Medical, user's manual) |
| Warranty | Five Years |
| Dimension Drawing | GIF |
