- LMM56800
- Tweet
- Diagnostic
- Clinical Review
- Digital Mammography
- Surgical
- Quality Control
- Features
- Specifications
- Documents
- Graphics Boards
- QC Software & Tools Accessories
All Gather In One
The Large Monitor Manager bundles up different signal sources and enables you control them from one location.
Common Interface
This network interface allows customer applications automated control of Large Monitor Managers. Layout changes and status information e.g. can directly be done from x-ray system.
Saving time by Optimizing Workflow
Individual image placement and window size preferences can be easily arranged and recalled using the Large Monitor Manager.
| Cabinet Color | Black |
|---|---|
| Interface Specifications | |
| Input Terminals |
Digital: HDMI connectors (DVI signals only) x 18 Digital /Analog: DVI-I x 3 Analog: D-Sub mini 15 pin x 3 21 simultaneous visible inputs |
| Input Performance |
Digital: DVI (single link), 1920 x 1200 maximum, 60 Hz (165 MHz pixelclock maximum, horizontal size 2048 maximum) Analog: max. 1600 x 1200, 60 Hz (3 Ports), 1280 x 1024 maximum, 75 Hz (3 Ports) |
| Output Terminals | DVI-D (Dual Link ) x 2 |
| Output Performance | (2048 x 2160) x 2 maximum |
| Communication Connector | Ethernet (RJ45) |
| Power | |
| Power Requirements |
AC 100 - 120 V, 200 - 240 V: 50 / 60 Hz Redundancy: 2 independent power supplies, hot swap capable |
| Power Consumption | 500 W |
| Physical Specifications | |
| Degree of Protection | IP20 |
| Net Weight | 20 kg |
| Mechanical Adaption | 19" rack design, 4 U high |
| Features & Functions | |
| Controls and Status | Software control interface for layout, status and diagnosis, LED Indicators for power supplies |
| Certifications & Standards (Please contact the EIZO subsidiary or distributor in your country for the latest information.) | EN60950-1, CAN/CSA C22.2 No.60950, UL60950, EN55022-Class-B, RoHS, China RoHS, WEEE |
| Supplied Accessories | AC power cord x 2, Utility Disk (user's manual) |
| Warranty | Two Years |
| Dimension Drawing | JPG |
Brochures
 |
|
Manuals
Please note that you must be a registered user to download RadiForce relevant files. If you have not registered, please continue on to our registration page. If you have forgotten your User ID or Password, please send us an e-mail.
| Document | Language | Size | Download |
|---|---|---|---|
| LMM56800 User's manual | English | 1.22 MB |  |
